TechniSystem 5/8 K (cascade) blue/yellow
PLN 544.00*
TechniSystem 5/8 K (cascade)
Multi-switch system with connection possibility of 4 ZF levels for distribution to up to 8 participants
PLN 544.00*
incl. VAT.
- Made in Germany; cascade module for professional multiswitch systems for implementing larger cable networks in residential units, complexes, and large facilities
- The professional system for Quattro LNBs features 4 satellite inputs, 1 terrestrial input, and 8 outputs
- No attenuation in the satellite band, with tilt compensation
- Attention: The components of the TECHNISYSTEM are not compatible with TECHNISWITCH components
- Scope of delivery: TechniSat TECHNISYSTEM 5/8 K (cascade), user manual
This cascadable matrix for eight receivers, can be used up to eight times in one trunk. The power supply is taken from a TechniSystem G or from a Line Amplifier 5 Z / NT.
Attention: These TechniSystem 5/8 G + 5/8 K are not compatible with TechniSwitch 5/8 G and 5/8 K.
Attention: These TechniSystem 5/8 G + 5/8 K are not compatible with TechniSwitch 5/8 G and 5/8 K.
You are free to install the software updates provided by TechniSat. However, TechniSat expressly points out that we are not liable for material defects that are solely due to the fact that you did not install the updates within a reasonable time, although TechniSat had informed you of their availability and provided you with a flawless installation guide.
| Product Information | |
|---|---|
| EAN | 4019588032484 |
| Colour | blue/yellow |
| Item no. | 0000/3248 |
| Weight (Box) | 400 g |
| Weight | 400 g |
| Device (W x H x D) | 17,1 x 10,13 x 3,3 cm |
| Box | 17,6 x 18,6 x 4 cm |
| sonstiges | |
|---|---|
| bf_filter_digital_single_cable_solution | No |
| Ambient operating conditions | |
|---|---|
| Ambient temperature | -25 ... 55 °C |
| Amplification | |
|---|---|
| Sat | -2 ... 3 dB |
| Terrestrial | 1 ... 4 dB |
| Decoupling | |
|---|---|
| Output | > 35 dB |
| Trunks | 47 dB |
| General characteristics | |
|---|---|
| Top features | No attenuation in satellite range |
| Top features | Tilt gain |
| Top features | For quad LNB |
| Reception range | |
|---|---|
| Sat | 950 ... 2.150 MHz |
| Terrestrial | 47 ... 862 MHz |
| Technical data | |
|---|---|
| Satellite inputs | 4 |
| Terrestrial input | 1 |
| Outputs | 8 |
| Distribution length | 100 m |
| Transmission loss | |
|---|---|
| Sat | 2 ... 5 dB |
| Terrestrial | 2 ... 3 dB |
