Antenna power supply ZCE3 black
PLN 49.99*
Antenna power supply ZCE3
Antenna power supplY 12V/200mA with a separator
PLN 49.99*
incl. VAT.
In addition to the statutory warranty, you can purchase a 3-year warranty for this product after registration. All information about warranty conditions
Antenna power supplY designed for TV and radio antennas equipped with an amplifier. It has a voltage separator, which allows the amplifier to be powered with the same cable that is used to connect the signal from the amplifier to the DVB-T/DVB-T2 receiver.
The universal antenna power supplY is designed to supplY 12 V DC (max 200 mA) antenna amplifiers and antenna preamplifiers. The power supplY should be used for active antennas equipped with an amplifier. Do not use the power supplY for passive antennas equipped with an impedance transformer.
The universal antenna power supplY is designed to supplY 12 V DC (max 200 mA) antenna amplifiers and antenna preamplifiers. The power supplY should be used for active antennas equipped with an amplifier. Do not use the power supplY for passive antennas equipped with an impedance transformer.
| Product Information | |
|---|---|
| EAN | 4019588113305 |
| Colour | Schwarz |
| Item no. | 0011/1133 |
| Weight (Box) | 120 g |
| Weight | 100 g |
| Device (W x H x D) | 8,5 x 4 x 2,5 cm |
| Box | 10,5 x 5 x 5 cm |
| Connections | |
|---|---|
| Connection 1 | Separator plug |
| General characteristics | |
|---|---|
| Top features | Designed for TV and radio antennas equipped with an amplifier 12 V DC (max 200 mA) |
| Top features | Separator with IEC plug |
| Top features | For DVB-T/DVB-T2 and DAB+ |
| Top features | Input voltage: AC 100-240V ~ 50/60 Hz, 0.2A |
| Top features | Output voltage: DC 12V; 0.2A (2.4W) |
| Power supply | |
|---|---|
| Nominal voltage | 240 V |
| Frequency | 50 Hz |
| Mains adapter | AC 100-240V ~ 50/60 Hz, 0.2A |
