IEC antenna cable; 1.5 m, white 76-4830-01
PLN 15.00*
IEC antenna cable; 1.5 m, white
Antenna cable with male and female IEC connectors packed in blister
PLN 15.00*
incl. VAT.
Content:
1.5 metr
(PLN 10.00 / 1 metr)
- Innenleiter aus massivem hochreinen Elektrolytkupfer!
- Braid made of aluminum
Antenna cable with male and female IEC connectors packed in blister
Antenna cable terminated with male and female IEC connectors. It allows you to connect a TV set or a set-top box to an RTV socket. Ready solution that does not require the assembly of plugs.
| Product Information | |
|---|---|
| EAN | 4019588783010 |
| Item no. | 76-4830-01 |
| Attenuation | |
|---|---|
| 45 MHz | 8,2 |
| 100 MHz | 9,5 |
| 200 MHz | 10,8 |
| 450 MHz | 14,8 |
| 800 MHz | 20,1 |
| 1000 MHz | 21,5 |
| 1750 MHz | 29 |
| 2250 MHz | 33,5 |
| Technical data | |
|---|---|
| Frequency range | 5 ... 2.250 MHz |
| Impedance | 75 Ω (± 3) |
| Inner cable diameter | 102 mm (18AWG) |
| Inner cable material | CCS (OFC) |
| Isolation | Zell-PE |
| Diameter dielectric | 4,65 mm (± 0,1) |
| Outer cable | 1x aluminum foil + 1x aluminum braid |
| Sheath | PVC |
| Diameter with coating | 6,8 mm (± 0,2) |
| Bending radius | ≥ 35 mm |
