TECHNIROUTER 9/4x16 silver/yellow
PLN 2,600.00*
PRODUCT NO LONGER AVAILABLE
TECHNIROUTER 9/4x16
(0000/3283)
Distribution of 4 satellites to 4 times 16 participants
| Product Information | |
|---|---|
| EAN | 4019588032835 |
| Colour | silver/yellow |
| Item no. | 0000/3283 |
| Weight (Box) | 1,3 kg |
| Weight | 1,01 kg |
| Device (W x H x D) | 21 x 4 x 18,7 cm |
| Box | 22 x 5 x 26,5 cm |
| LNB control | |
|---|---|
| Current consumption | max. 500 mA |
| Ambient operating conditions | |
|---|---|
| Humidity | 10 ... 75 % |
| Ambient temperature | -25 ... 45 °C |
| Amplification | |
|---|---|
| Sat | 0 ... 30 dB AGC controlled |
| Terrestrial | -16 dB relative to input |
| Return path | -16 dB |
| Decoupling | |
|---|---|
| Trunks | ≥ 30 dB |
| General characteristics | |
|---|---|
| Top features | 64 participants on four cables |
| Top features | SCR protocol according to EN 50494 & EN50607 |
| Top features | 4 orbit positions - for quattro or wideband LNB operation |
| Top features | Automatic gain control (AGC) |
| Top features | SCR level adjustable |
| Power supply | |
|---|---|
| Nominal voltage | 230 V |
| Frequency | 50 Hz |
| Mains adapter | external DC 12V/2,0A |
| Power consumption | 80 mA @13V, each SCR output |
| Reception range | |
|---|---|
| Terrestrial | 5 ... 862 MHz |
| Sat | 290 ... 2.340 MHz |
| Single-cable output | |
|---|---|
| Output frequency | 5 ... 2.150 MHz |
| Number of output channels | 4x 16 |
| Frequency of the output channels | 1210, 1420, 1680, 2040, 985, 1050, 1115, 1275, 1340, 1485, 1550, 1615, 1745, 1810, 1875, 1940 MHz |
| Frequency SAT | 950 ... 2.150 MHz |
| Frequency DVB-T | 5 ... 790 MHz |
| Output level | ≤ 90 typ. |
| Technical data | |
|---|---|
| Satellite inputs | 8 |
| Terrestrial input | 1 |
| Number of cable connections | 4 |
| Subscribers per cable | 16 |
| Transmission loss | |
|---|---|
| Sat | ≤ 2 dB |
| Terrestrial | ≤ 2 dB |
