TECHNIROUTER 5/1x8 K-R silver/yellow
PLN 850.00*
PRODUCT NO LONGER AVAILABLE
TECHNIROUTER 5/1x8 K-R
(0001/3291)
TECHNIROUTER cascade, return channel compatible. Enables the connection of 4 IF levels (satellite blocks) and one terrestrial input for distribution to a cable run for 8 users
| Product Information | |
|---|---|
| Colour | silver/yellow |
| EAN | 4019588132917 |
| Item no. | 0001/3291 |
| Weight (Box) | 426 g |
| Weight | 260 g |
| Device (W x H x D) | 14 x 13 x 3,2 cm |
| Box | 24,5 x 13,5 x 5,5 cm |
| Filter-Navigation | |
|---|---|
| Number participants | 8 |
| Ambient operating conditions | |
|---|---|
| Ambient temperature | -25 ... 55 °C |
| Humidity | 10 ... 75 % |
| Amplification | |
|---|---|
| Sat | 13 ... 18 dB |
| Terrestrial | -8 dB |
| Decoupling | |
|---|---|
| Trunks | 45 dB |
| General characteristics | |
|---|---|
| Top features | DiSEqC according to EN 50494 |
| Top features | 1 orbit position without restrictions |
| Top features | Return channel compatible |
| Top features | No new wiring required |
| Top features | Energy-saver - can be used without power supply |
| Top features | Can be integrated into a multi-switch distribution |
| Power supply | |
|---|---|
| Power consumption | 210 mA @13V (SCR-Ausgang) |
| Reception range | |
|---|---|
| Return path | 5 ... 65 MHz |
| Terrestrial | 65 ... 862 MHz |
| Sat | 950 ... 2.150 MHz |
| Single-cable output | |
|---|---|
| Output frequency | 5 ... 2.150 MHz |
| Number of output channels | 8 |
| Frequency of the output channels | 1284, 1400, 1516, 1632, 1748, 1864, 1980, 2096 MHz |
| Frequency SAT | 950 ... 2.150 MHz |
| Frequency DVB-T | 65 ... 862 MHz |
| Technical data | |
|---|---|
| Satellite inputs | 4 |
| Terrestrial input | 1 |
| Number of cable connections | 1 |
| Subscribers per cable | maximal 8 |
| Transmission loss | |
|---|---|
| Sat | 2 ... 5 dB |
| Terrestrial | 2 ... 3 dB |
| Tuner | |
|---|---|
| TECHNIROUTER ready | Yes |
