TECHNIDISH 80 cm, graphie (5 pcs per box)

Satellite antenna with a diameter of 80 cm with an AZ/EL holder for receiving a digital DVB-S/DVB-S2 signal.

Colour slate/grey

PLN 472.00*

incl. VAT.

TECHNIDISH 80 satellite dish, AZ/EL holder, 40 mm mount, user manual, converter * (depending on the set).

In addition to the statutory warranty, you can purchase a 3-year warranty for this product after registration. All information about warranty conditions

TECHNIDISH 80 antennas are made of the highest qualitY steel and painted with powder paint. Thanks to this, it is highlY resistant to rust and extreme weather conditions. The diameter of the antenna is 80 cm. The precise construction of the antenna guarantees effective reception of digital satellite television throughout Europe. The TechniDish 80 antenna has a universal mounting bracket for 40 mm LNBs.
The antenna plate is available in two colors: beige and graphite.
Available in sets with Single (1 user), Twin (2 users, or Twin decoder) and without converters.

Technical Datasheet ( HTML / PDF )

html

Product Information
EAN	4019588805309
Colour	grafirowy
Item no.	1080/0530

General characteristics
Top features	For 1 to multiple participants
Top features	1 orbital position (for example Astra 19.2° East)
Top features	Ideal for wall and roof mounting
Top features	For distribution to multiple participants on demand, TechniSat distribution elements are required
Coating	Powder-coated on both sites
Material	steel

Input frequency range
Low band	10,7 ... 11,7 GHz
High band	11,7 ... 12,75 GHz

Prepared for
Number of orbit positions	1

Technical data
Rated measurement	0,8 m
F/D	0,64
Gain	38,1 dBi @11,3 GHz
Offset angle	26 °
Mast Ø	50 mm
Feed reception	LNB retaining clamp (40mm)
