SATMAN 65 PLUS with SCR-LNB

SATMAN 65 PLUS with SCR-LNB

SATMAN external unit with pre-assembled AZ/EL mount, 65 cm Ø
EAN Colour Item no. Weight (Box) Weight Device (W x H x D) Box
4019588888654 yellow with Smiley 2565/8886 8,8 kg 5,2 kg 68 x 76 x 5,8 cm 69,2 x 77,8 x 19,5 cm
4019588888760 polar white 2765/8886 8,8 kg 5,2 kg 68 x 76 x 5,8 cm 69,2 x 77,8 x 19,5 cm
4019588888630 slate/grey 2365/8886 8,8 kg 5,2 kg 68 x 76 x 5,8 cm 69,2 x 77,8 x 19,5 cm
4019588888647 brick/red 2465/8886 8,8 kg 5,2 kg 68 x 76 x 5,8 cm 69,2 x 77,8 x 19,5 cm
4019588888609 beige 2065/8886 8,8 kg 5,2 kg 68 x 76 x 5,8 cm 69,2 x 77,8 x 19,5 cm
Top Features
  • 65 cm Spiegel aus erstklassigem Aluminium (beidseitig pulverbeschichtet)
  • Inkl. SCR-LNB
  • Ausgelegt für den 6-Teilnehmer-Empfang
  • 4 Teilnehmer über SCR
  • 2 Teilnehmer über Legacy
  • 1 Orbitposition (z. B. Astra 19,2° Ost)
  • Optimal für Wand- und Dachmontage
Local oscillator
Low band: 9,75 GHz
High band: 10,7 GHz
LNB control
Vertical: 11,5 - 14,5 V
Horizontal: 16 - 19 V
General characteristics
Material: Aluminium
Material strength: 1,5 mm
Coating: Powder-coated on both sites
Colour: beige, slate-grey, brick-red, green
Input frequency range
Low band: 10,7 ... 11,7 GHz
High band: 11,7 ... 12,75 GHz
Noise factor
Lower frequency range: 0,6 dB max.
Upper frequency range: 0,6 dB max.
Output frequency range
Low band: 950 ... 1.950 MHz
High band: 1.100 ... 2.150 MHz
Prepared for
Number of orbit positions: 1
Number of clients: 6
Single-cable output
Output frequency: 950 ... 2.150 MHz
Number of output channels: 4
Frequency of the output channels: 1210, 1420, 1680, 2040 MHz
Technical data
Rated measurement: 0,65 m
F/D: 0,69
G/T: 14,5
Offset angle: 27 °
Gain: 35,7 dBi @11,3 GHz
Mast Ø: 65 mm max.
Feed reception: for UNYSAT-Universal-LNB
Scope of Delivery
Satellite dish antenna SATMAN 65, AZ/EL bracket mount, SCR LNB, screws, installation instructions
