EUTELASTRASAT 850, 2 participant
With the TechniSat EUTELASTRASAT appliance you receive the TV and radio programmes of ASTRA 19.2° East and EUTELSAT 13° East
| EAN | Colour | Item no. | Weight (Box) | Weight | Device (W x H x D) | Box |
|---|---|---|---|---|---|---|
| 4019588742826 | brick/red | 9742/8882 | 9,6 kg | 6 kg | 85 x 87 cm | 88 x 95 x 24 cm |
| 4019588752825 | yellow with Smiley | 9752/8882 | 9,6 kg | 6 kg | 85 x 87 cm | 88 x 95 x 24 cm |
| 4019588297081 | beige | 9702/8882 | 9,6 kg | 6 kg | 85 x 87 cm | 88 x 95 x 24 cm |
| 4019588732827 | slate/grey | 9732/8882 | 9,6 kg | 6 kg | 85 x 87 cm | 88 x 95 x 24 cm |
| 4019588772823 | polar white | 9772/8882 | 9,6 kg | 6 kg | ||
| 4019588722828 | fir/green | 9722/8882 | 85 x 87 cm | 88 x 95 x 24 cm |
| Local oscillator |
|---|
| Low band: 9,75 GHz ± 3MHz |
| High band: 10,6 GHz ± 3MHz |
| LNB control |
|---|
| Vertical: 11,5 - 14,5 V |
| Horizontal: 16 - 19 V |
| General characteristics |
|---|
| Top features: Für 2 Teilnehmer |
| Material: Aluminium |
| Top features: 2 Orbitpositionen (Astra 19,2° Ost und Eutelsat Hotbird 13° Ost) |
| Top features: Optimal für Dachmontage |
| Material strength: 1,6 mm |
| Coating: Powder-coated on both sites |
| Input frequency range |
|---|
| Low band: 10,7 - 11,7 GHz |
| High band: 11,7 - 12,75 GHz |
| Noise factor |
|---|
| Lower frequency range: 0,6 dB max. |
| Upper frequency range: 0,6 dB max. |
| Output frequency range |
|---|
| Low band: 950 - 1.950 MHz |
| High band: 1.100 - 2.150 MHz |
| Technical data |
|---|
| F/D: 0,67 |
| G/T: 17,2 |
| Gain: 38,2 dBi @11,3 GHz |
| Offset angle: 21 ° |
| Satellite positions: Eutelsat 13° east, ASTRA 19,2° east |
| Mast Ø: 65 mm max. |
| Feed reception: for UNYSAT-Universal-LNB |
| Scope of Delivery |
|---|
| Satellite dish, 2x Unysat V/H LNB in a weatherproof housing, AZ/EL mount (with Multifeed-mount), 1x TechniSwitch 2/1 DiSEqC switch, screws, tools, instruction manual |
