SATMAN 45 with UNYSAT-24TN-LNB

SATMAN 45 with UNYSAT-24TN-LNB

Set consisting of satellite antenna SATMAN 45 and UNYSAT-24TN-LNB
EAN Colour Item no. Weight (Box) Weight
4019588548244 yellow with Smiley 1545/8824 3,9 kg 3,1 kg
4019588348240 slate/grey 1345/8824 3,9 kg 3,1 kg
4019588448247 brick/red 1445/8824 3,9 kg 3,1 kg
4019588748248 polar/white 1745/8824 3,9 kg 3,1 kg
4019588048249 beige 1045/8824 3,9 kg 3,1 kg
Top Features
  • Dish only 45 cm small made of first-class aluminum (powder-coated on both sides)
  • Up to 24 participants on one cable
  • Participants 1-8 work with EN50494 or EN50607
  • From participant 9 onwards, only EN50607 is used
  • Ideal for roof mounting
  • With antenna adjustment mode, transponder 85 with 18V control
  • LNB with weatherproof housing
sonstiges
bf_filter_number_satellites: 1
bf_filter_number_of_participants: 24
bf_filter_austattung: with LNB
bf_filter_diameter: 45 cm
Local oscillator
Low band: 9,75 GHz
High band: 10,7 GHz
LNB control
Vertical: 11,5 - 14,5 V
Horizontal: 16 - 19 V
General characteristics
Material: Aluminium
Material strength: 1 mm
Coating: Powder-coated on both sites
Colour: beige, polar white, slate-grey, brick-red
Input frequency range
Low band: 10,7 ... 11,7 GHz
High band: 11,7 ... 12,75 GHz
Noise factor
Lower frequency range: 1 dB max.
Upper frequency range: 1 dB max.
Output frequency range
Low band: 950 - 1.950 MHz
High band: 1.100 - 2.150 MHz
Power supply
Power consumption: max. 350 mA @13,5 V
Prepared for
Number of orbit positions: 1
Number of clients: 24
Single-cable output
Output frequency: 950 ... 2.150 MHz
Number of output channels: 24
Frequency of the output channels: 975, 1025, 1075, 1125, 1175, 1225, 1275, 1325, 1375, 1425, 1475, 1525, 1575, 1625, 1675, 1725, 1775, 1825, 1875, 1925, 1975, 2025 MHz
Technical data
Rated measurement: 0,45 m
F/D: 0,6
Gain: 32,2 dBi @11,3 GHz
Offset angle: 30 °
Feed reception: for UNYSAT-Universal-LNB
Scope of Delivery
DigitalSat antenna SATMAN 45, AZ / EL bracket, UNYSAT-24TN-LNB (0000/8824), screws, assembly instructions
